BSPT Fireann Go BSP Cuibheoir Díreach Mná
Cruth: Díreach
Cineál Snáithe 1: BSPT fireann
Cineál Snáithe 2: BSP Mná
BSPT Fireann go BSP Cuibheoir Díreach Mná
Uimhir Pháirt:
2TB
Tréithe:
Cruth: Díreach
Cineál Snáithe 1: BSPT fireann
Cineál Snáithe 2: BSP Mná
Snáithe A | Snáithe B | Cuid Uimh | E | L | N | H1 | H | ||
Fleasc | BSPT | Fleasc | BSP | mm | mm | mm | mm | mm | |
-02 | 1/8-28 | -02 | 1/8-28 | 2TB-0202 | 10.2 | 25.0 | 4.0 | 12 | 14 |
-02 | 1/8-28 | -04 | 1/4-19 | 2TB-0204 | 10.2 | 27.0 | 5.0 | 12 | 19 |
-04 | 1/4-19 | -02 | 1/8-28 | 2TB-0402 | 15.0 | 30.0 | 4.0 | 17 | 14 |
-04 | 1/4-19 | -04 | 1/4-19 | 2TB-0404 | 15.0 | 31.5 | 5.0 | 17 | 19 |
-04 | 1/4-19 | -06 | 3/8-19 | 2TB-0406 | 15.0 | 33.0 | 6.0 | 19 | 22 |
-04 | 1/4-19 | -08 | 1/2-19 | 2TB-0408 | 15.0 | 36.5 | 7.0 | 19 | 27 |
-06 | 3/8-19 | -04 | 1/4-19 | 2TB-0604 | 15.0 | 30.9 | 5.0 | 19 | 19 |
-06 | 3/8-19 | -06 | 3/8-19 | 2TB-0606 | 15.0 | 33.0 | 6.0 | 19 | 22 |
-06 | 3/8-19 | -08 | 1/2-14 | 2TB-0608 | 15.0 | 35.0 | 7.0 | 19 | 27 |
-08 | 1/2-14 | -04 | 1/4-19 | 2TB-0804 | 20.3 | 35.0 | 5.0 | 22 | 19 |
-08 | 1/2-14 | -06 | 3/8-19 | 2TB-0806 | 20.3 | 41.2 | 6.0 | 22 | 22 |
-08 | 1/2-14 | -08 | 1/2-14 | 2TB-0808 | 20.3 | 42.0 | 7.0 | 22 | 27 |
-08 | 1/2-14 | -12 | 3/4-14 | 2TB-0812 | 20.3 | 45.0 | 9.0 | 27 | 32 |
-12 | 3/4-14 | -08 | 1/2-14 | 2TB-1208 | 20.3 | 45.7 | 7.0 | 30 | 27 |
-12 | 3/4-14 | -12 | 3/4-14 | 2TB-1212 | 20.3 | 45.0 | 9.0 | 30 | 32 |
-12 | 3/4-14 | -16 | 1-11 | 2TB-1216 | 20.3 | 49.6 | 9.0 | 32 | 38 |
-16 | 1-11 | -12 | 3/4-14 | 2TB-1612 | 25.4 | 49.3 | 9.0 | 36 | 32 |
-16 | 1-11 | -16 | 1-11 | 2TB-1616 | 24.5 | 53.9 | 9.0 | 36 | 38 |
-16 | 1-11 | -20 | 1.1/4-11 | 2TB-1620 | 27.0 | 59.6 | 9.0 | 46 | 50 |
-20 | 1.1/4-11 | -16 | 1-11 | 2TB-2016 | 27.0 | 57.0 | 9.0 | 46 | 38 |
-20 | 1.1/4-11 | -20 | 1.1/4-11 | 2TB-2020 | 27.0 | 58.6 | 11.0 | 46 | 50 |
-24 | 1.1/2-11 | -24 | 1.1/2-11 | 2TB-2424 | 27.0 | 62.5 | 12.0 | 50 | 55 |
-32 | 2-11 | -32 | 2-11 | 2TB-3232 | 30.0 | 69.1 | 16 | 65 | 70 |
